Powerful, versatile and economical tow tractor to pull trailers up to 10,000 kg.

Our tractors are particularly efficient when used in the production supply and in the handling of interior and exterior material with a trailer train. Our versatile VTA 305-310 is ideal for towing heavier trailers. It also represents an economical solution for trailer tractors used for longer operations. It provides optimum safety by combining braking systems: regenerative electric brake and electromagnetic parking brake.

Ergonomics
The new range of seats with different levels of suspension, its integral armrest adjustable in height and depth in a single action, together with the telescopic and tilting column gives the driver maximum ergonomics.

Flux Vector Control
Latest technology programming. Intelligent adaptation to work needs, determining in each case the minimum battery consumption.

Display
The programming for the maintenance and the adjustment of the parameters can be done from the big screen, as well as through the Tecna service tool (TST).

Battery
Lateral removal of the battery in all models. Li-ion batteries available throughout the range.

High performance motors
The high power of the two traction motors, all asynchronous (maintenance free) guarantees an extremely high dynamic response in any situation.

Brakes
Braking system based on fully encapsulated oil-coated discs.

Comfort
The protective cabin is floating on hydraulic shock absorbers to transmit maximum comfort to the driver, eliminating vibrations and reducing the noise level.

More information about VTA 300 available on Tecnacar website.

  • VTA300
  • VTA310
  • VTA307
  • VTA300
  • VTA
  • VTA300
  • VTA300
  • VTA300

Technical Data

ModelsVTA 305 / VTA 306 / VTA 307 / VTA 308 / VTA 309 / VTA 310
CapacitiesFrom 5,000 kg to 10,000 kg
Nominal bar shootingFrom 1,400 N to 2,000 N
WheelbaseFrom 1,048 mm to 1,268 mm
WeightFrom 1,046 kg to 1,600 kg
Track width in front146 mm
Track width behind808 mm
Total height1,970 mm
Total length1,730 mm
Total width970 mm
Turning radiusFrom 1,624 mm to 1,844 mm
Travel speed with/without load10/18 km/h
Maximum shot at the barFrom 5,000 N to 8,300 N
Motor power2 x 4.3 kW (8.6 kW)
Batteries48V 270 Ah / 48V 300 Ah / 48V 400 Ah / 48V 450 Ah
